Windshield, door glass, quarter panel glass, compl |
| Complete windshield and window glass kit for all Diablo replica/kit cars.
The COUPE kit consists of laminated windshield, two door window glasses and quarter panel glasses that may be laminated or tempered (your choice) ONLY.
The ROADSTER kit consists of laminated windshield and two tempered door window glasses ONLY.
The fixed rear glass is not included in either kit. This is a small piece of flat glass that may be cut to fit inexpensively by your local auto glass shop.
PLEASE NOTE that because there are/were so many manufacturers of body kits, we CANNOT guarantee the fit of these glasses to your body. You MUST check the dimensions of your body kit and compare them to the dimensions shown below. Returns are allowed ONLY for manufacturer defects. These glasses are manufactured by a major North American auto glass manufacturer to the original Lamborghini factory OEM dimensions, and should fit your body kit if it is manufactured to the same dimensions.
COUPE glass dimensions:
Coupe windshield: Top-Bottom measuring from the inside middle down: 38 inches. Top Left-Right (corner- corner): 39 1/2 inches. Widest point where it wings out: 60 inches across.
Coupe door glass: Left-Right: 41 3/4 inches.
Top–Bottom: 16 3/4 inches.
Coupe quarter glass: Top–Bottom: 14 inches.
Left–Right: 18 inches.
ROADSTER glass dimensions:
Roadster windshield: Top-Bottom measuring from the inside middle down: 38 inches. Top Left-Right (corner- corner): 39 1/2 inches. Widest point where it wings out: 60 inches across (same as Coupe).
Roadster door glass: Left-Right: 38 1/2 inches.
Top–Bottom: 17 3/8 inches.
Please send us your zip code for a shipping quotation. Delivery must be to a business address with a loading dock or to a freight terminal. Shipment will be in a custom-fabricated crate. Crating and shipping will usually be completed within 4 business days of receipt of cleared funds. We accept PayPal, cashier's check or money order only. |
Condition Code: 1
Excellent condition either new or almost new condition |
|
Located in:
Varies with destination |
|
Lamborghini PN#: Leave if Unknown |
| Model:
Diablo |
| Year:
All years |
|
|
|
|
